8.1 Data storage

Introduction

Data in a database must be stored somewhere. The performance of a database system depends heavily on how and where data is stored, how it moves between storage levels, and how the storage hardware works.

Storage hierarchy

Computer storage is organized as a hierarchy. As you go down the hierarchy, capacity increases, cost per byte decreases, and access speed decreases.

Cache memory. Small, fast, expensive. Located on the CPU chip. Access time is a few nanoseconds.
Main memory (RAM). Larger than cache (gigabytes). Access time is tens of nanoseconds. Volatile — data is lost on power failure.
Flash memory (SSD). Non-volatile, faster than HDD. Used in laptops, servers, and phones.
Magnetic disk (HDD). Large capacity (terabytes). Access time is milliseconds. Non-volatile.
Tape / archival storage. Very large capacity. Sequential access only. Used for backups.

The hierarchy matters because a database cannot keep all its data in main memory. Most data lives on disk. When a query needs data, the system moves it from disk to memory. The time to read from disk is orders of magnitude larger than the time to read from memory.

Volatile versus non-volatile storage

Volatile storage. Cache and main memory lose their contents when power is lost or the system crashes.
Non-volatile storage. Disks, SSDs, and tape retain data across power failures and crashes.

Database systems must ensure that committed data is written to non-volatile storage. This is the durability requirement of ACID.

Magnetic disk

A magnetic disk stores data on spinning platters coated with magnetic material. Each platter has concentric rings called tracks. Each track is divided into sectors. A set of tracks at the same radius across all platters is called a cylinder.

A read-write head floats above each platter surface. All heads move together on a single arm assembly.

Disk access time

The time to read or write a block on disk has three components:

Seek time. The time to move the read-write head to the correct track. This is the largest component, typically 4–10 milliseconds.
Rotational latency. The time for the desired sector to rotate under the head. On average, this is half the rotation time. For a 7200 RPM disk, average rotational latency is about 4.17 milliseconds.
Transfer time. The time to move data from the disk surface to the controller. This depends on the rotational speed and the number of bytes transferred.

Total access time = seek time + rotational latency + transfer time.

Sequential versus random access

Sequential access. Reading consecutive blocks. The seek happens once, then blocks pass under the head as the disk rotates. Very fast.
Random access. Reading blocks at arbitrary locations. Each block requires a new seek and rotational delay. Much slower than sequential access by a factor of 10 to 100.

Database systems try to organize data so that most access is sequential. Indexes and file organization methods are designed with this in mind.

Performance metrics of disks

Metric	Typical value
Capacity	1–20 TB
Rotation speed	5400–15000 RPM
Average seek time	4–10 ms
Average rotational latency	2–6 ms
Transfer rate	100–600 MB/s
Mean time to failure	1–1.5 million hours

Flash memory (SSD)

Solid-state drives use NAND flash memory. They have no moving parts, so there is no seek time or rotational latency. Access times are in the range of tens to hundreds of microseconds, orders of magnitude faster than HDDs.

However, SSDs have two important limitations:

Write cycles are limited. Each flash cell can be written a finite number of times (typically 10,000 to 100,000). The drive uses wear leveling to spread writes across all cells.
Writes are slow. Writing to flash requires erasing an entire block first. Random writes are particularly slow compared to reads.

Most modern database systems are designed with both HDD and SSD characteristics in mind. SSDs are often used for high-performance workloads, while HDDs are used for bulk storage.

RAID

RAID (Redundant Array of Independent Disks) combines multiple physical disks into a single logical unit. The goals are:

Performance. Multiple disks can be accessed in parallel.
Reliability. Redundancy allows recovery from disk failures.

RAID levels

Different RAID levels offer different trade-offs between performance, capacity, and reliability.

RAID 0 (Striping). Data is split across multiple disks. Any disk failure destroys all data. No redundancy.

RAID 1 (Mirroring). Each disk has an identical copy. Reads can be served from either disk, improving read performance. Write performance is slower because both disks must be updated.

RAID 5 (Striping with parity). Data and parity information are striped across all disks. A single disk failure can be tolerated by recomputing the lost data from the remaining disks and parity. Parity requires at least 3 disks.

RAID 6 (Striping with dual parity). Similar to RAID 5 but uses two parity blocks. Can tolerate two simultaneous disk failures. Requires at least 4 disks.

RAID 10 (RAID 1 + 0). Combines mirroring and striping. Disks are mirrored in pairs, then striped across the pairs. Good performance and good reliability, but only 50% capacity utilization.

Buffer management

The database buffer manager is responsible for moving data between disk and main memory. It manages a pool of memory pages called the buffer pool.

When a page is requested:

If the page is already in the buffer pool, it is returned immediately.
If the page is not in the buffer pool, the buffer manager reads it from disk into a free buffer frame.
If no free frame is available, a page is evicted using a replacement policy.

Buffer replacement policies

LRU (Least Recently Used). Evict the page that has not been accessed for the longest time. Works well for many workloads.
Clock policy. An approximation of LRU that avoids the overhead of maintaining a precise LRU order. Each page has a reference bit. When a page is accessed, its bit is set to 1. The clock hand sweeps through pages, clearing bits until it finds a page with bit 0 to evict.
MRU (Most Recently Used). Evict the most recently used page. Useful for scans where pages are unlikely to be re-referenced.
LRU-k. Tracks the last k accesses to each page. More accurate than LRU for database workloads.

Pinned pages

Some pages must stay in the buffer pool and cannot be evicted. These are called pinned pages. For example, pages that are currently being updated or pages that contain index root nodes are pinned.

Buffer management and performance

The hit ratio of the buffer pool has a large impact on performance. If 90% of page requests are served from the buffer pool, the effective access time is close to main memory speed. If the hit ratio drops to 50%, performance is dominated by disk access times.

The size of the buffer pool and the replacement policy determine the hit ratio. Database administrators tune these parameters based on the workload.

Summary

Data in a database lives on non-volatile storage (disk or SSD).
Storage is organized hierarchically: cache → memory → disk → tape.
Disk access involves seek, rotational latency, and transfer.
RAID provides performance and reliability through disk arrays.
The buffer manager manages data movement between disk and memory.
Buffer replacement policies (LRU, Clock, MRU) affect performance.
